This document specifies requirements for six types of wire-braid-reinforced hoses and hose assemblies of nominal size from 5 to 51. This document also specifies the hose of nominal size 63 for types 2SN and R2AT, and the hose of nominal size 76 for type 2SN.

u000b

They are suitable for use with:

u000bu000boil-based hydraulic fluids HH, HL, HM, HR and HV as defined in ISO6743-4 at temperatures ranging from 40°C to +100°C;u000bwater-based fluids HFC, HFAE, HFAS and HFB as defined in ISO6743-4 at temperatures ranging from 40°C to + 70°C;u000bwater at temperatures ranging from 0°C to + 70°C.u000bu000b

This document does not apply to the connection ends. It is limited to the performance of hoses and hose assemblies.

u000b

NOTE 1 The hose assembly maximum working pressure is governed by the lowest maximum working pressure of the components.

u000b

NOTE 2 It is the responsibility of the user, in consultation with the hose manufacturer, to establish the compatibility of the hose with the fluid to be used.

Product Details

Published:

01/01/2026

File Size:

1 file , 630 KB

Note:

This product is restricted and cannot be purchased in the following countries Ukraine, Russia, Belarus
